PANEL MODUL P4 RGB FULL COLOR OUTDOOR
Pixel Pitch: 4mm
Pixel Configuration: 1R1G1B
Pixel Density: 62,500 dot/
Module Size: 320*160mm
Module Pixel: 80dot*40dot=3200dot
View Angle:
Horizontal 150Vertical 120
Best View Distance: 4m50m
Work Temperature: -1075
Environment Humidity: 10%90%RH
Storage Temperature: -30C+90C
Protection Grade: IP65
System Guard: Moistureproof, dust proof, resist high temperature, corrosion prevention, prevent burn, static-free, shock resistant, resist lightning
Supply Voltage: AC110V220V15%4065Hz
Average Power: 380w/
Max. Power: 480w/
GPU: DVI GPU
Diving Method: Constant Current
Refresh Rate: 1920Hz
Frame Frequency: 60Hz
Grayscale: Single Color 16384 Level
Color: 10.7 Hundred Million
Brightness: 4500CD/M2
Scan mode: 1/10
Brightness Adjustment: Manual & Automatically
Video Signal: RF,S-Video,RGB,RGBHV,YUV,YC,.etc
Control System: PCTVDVI GPUMaster cardNetwork Cable
Mean Time Between Failure: 10000 hour
Lifetime: 100 thousand hours
Flatness: Between adjacent pixels0.5mm
Brightness Uniformity: Pixel light intensity, MODULE brightness is balance0.1
Malfunction dot rate:0.0001
Effective Communication Distance: National transmission distance 100m,Optical fiber transmission distance100m
